Multitalented. Indispensable. Proficient.
MHS 850/1000
The multi-talented - Ideal for the buchtery trade, supermarkets and canteen kitchens
They do what the’re supposed to. With a throughput of up to 1100kg/h, the convincing MHS 850 and MHS 1000 multi-purpose dicers are the indispensable all-rounders for the butchery trade, supermarkets and canteen kitchens.
The MHS 850/1000 are perfect for cutting cubes, strips and slices of sausage products, meat as well as vegetables and many other products.
![mhs850_gesamt](/fileadmin/_processed_/7/6/csm_mhs850_gesamt_c21f1249c5.jpg)
Simple & uncomplicated
Operation
Immediately usable without long training periods for the staff.
- Easy to operate thanks to clear symbols via rotary knobs and buttons
- Ergonimical one-handed operation of the horizontal slider
- Dual chamber system with simultaneous machine loading and slicing
- Tool-free change of cutting sets in a short time
- Automatic start when closing the horizontal slider
![mhs850_bedienung](/fileadmin/_processed_/8/d/csm_mhs850_bedienung_3b3fd02feb.png)
![mhs850_schneidsystem](/fileadmin/_processed_/7/8/csm_mhs850_schneidsystem_62de69a4a8.jpg)
Smart
Cutting System
Perfectly sliced and perfectly portioned.
- Clean cuts thanks to the cutting grid’s very long stroke
- Adjustable horizontal compression
- Choice of clocked or continuous feeding
- 4-side pre-compression for increased cutting quality (optional)
- Long service life thanks to high powered drives
- MHS 850: up to max. 850 kg/h
- MHS 1000: up to max. 1000 kg/h
- Up to 500 slices/minute
Maximum
Hygiene
Easy and fast cleaning.
- Good accessibility to the individual components
- Easy to clean without tools in just a few steps
![mhs850_hygiene](/fileadmin/_processed_/8/d/csm_mhs850_hygiene_d25e02d2cb.png)
![mhs850_wirtschaftlichkeit](/fileadmin/_processed_/8/3/csm_mhs850_wirtschaftlichkeit_12f2a0b4ca.jpg)
Individual
Configuration
Perfectly matched to your needs.
- Grids for cutting cubes, strips and slices in different sizes
- Slicing discs for cutting slices
- Slicing discs for cutting strips
- Rasping disc for cutting rasps
- Special cheese grid for cutting cheese
- Machine movable on rollers
- Comprehensive range of accessories
Multiple
Cutting options
Ideal for cutting cubes, strips and slices
- Meat and sausages
- Fish and seafood
- Cheese and eggs
- Vegetables and fruit
- Fresh, chilled or frozen (to -3°C)
Original. Fitting. Professional.
Accesories
![Schneidscheibe](/fileadmin/_processed_/6/d/csm_Schneidscheibe_79a7a4ae34.jpg)
Accesories
Slicing discs
For example with quadruple sickle blade for cutting slices.
![2D_Schneidscheibe](/fileadmin/_processed_/a/2/csm_2D_Schneidscheibe_e5ef717775.jpg)
Accesories
Two-dimensional Slicing disc
For cutting julienne strips.
![Schneidrahmen](/fileadmin/_processed_/d/e/csm_Schneidrahmen_96f24a283a.jpg)
Accesories
Cutting frame
For cutting slices
![Drahtgatter](/fileadmin/_processed_/d/f/csm_Drahtgatter_d6de08a37f.jpg)
Accesories
Wire grid set
For cutting soft cheese.
![Wechselrahmen](/fileadmin/_processed_/f/f/csm_Wechselrahmen_ffa1b49267.jpg)
Accesories
Fix blade grid set
For cutting hard cheese.
![Buegelmesser](/fileadmin/_processed_/d/0/csm_Buegelmesser_02f4e284d9.jpg)
Accesories
Bow knife
For e.g. soft cheese.
Technical
Data
MHS 850-90 | MHS 850-96 | MHS 1000-90 | MHS 1000-96 | |
Max. input length (in mm) | 310 | 310 | 530 | 530 |
Cross section mm (WxH) | 90 x 90 | 96 x 96 | 90 x 90 | 96 x 96 |
Cutting grid cross-section (WxH) in mm | 90 x 90 | 90 x 90 | 90 x 90 | 90 x 90 |
Throughput (kg/h) | 850 | 950 | 1000 | 1100 |
Cutting length (mm) | 0 - 35 | 0 - 35 | 0 - 35 | 0 - 35 |
Grid sizes (mm) | 4, 5, 6, 7, 8, 10, 13, 15, 18, 22, 30, 45 | 4, 5, 6, 7, 8, 10, 13, 15, 18, 22, 30, 45 | 4, 5, 6, 7, 8, 10, 13, 15, 18, 22, 30, 45 | 4, 5, 6, 7, 8, 10, 13, 15, 18, 22, 30, 45 |
Dimensions (WxDxH) in mm | 1100 x 650 x 1065 | 1100 x 650 x 1065 | 1520 x 650 x 1065 | 1520 x 650 x 1065 |
Connection 3Ph + PE (other voltage on request) | 2,6 kW / 400 V / 50 Hz | 2,6 kW / 400 V / 50 Hz | 2,6 kW / 400 V / 50 Hz | 2,6 kW / 400 V / 50 Hz |
Weight (in kg) | 250 | 250 | 290 | 290 |
Suitability | Butchers | Butchers | Butchers | Butchers |
Adjustable pre-compression | yes | yes | yes | yes |
4-side pre-compression | - | yes | - | yes |
Side pre-compression | - | - | - | - |
Adjustable blade and grid speed | - | - | - | - |
Integrated conveyor belt | - | - | - | - |
Automatic loading | - | - | - | - |
Column feeding | - | - | - | - |
Pedestal | - | - | - | - |
